TM65-I 400mm LCD
BRAND: S+S REGELTECHNIK
DEVICE TYPE: TRANSMITTER
MEASUREMENTS: TEMPERATURE
COMPATIBILITY: CURRENT SIGNAL(4…20mA)
DISPLAY TYPE: DISPLAY
POWER SUPPLY: 24VDC
HOUSING FEATURES: WHITE / PLASTIC HOUSING / WITH QUICK-LOCKING SCREWS
ADDITIONAL DESCRIPTION: IN TO IMMERSION SLEEVE / IN TO MOUNTING FLANGE
MEASURING RANGE: –50...+150 °C
FACTORY SETTINGS: +0…+50°C
PROBE LENGTH: 400MM
PROBE THICKNESS: 6MM
MEASUREMENT TYPE: PROBE MEASUREMENT
APPLICATION: LIQUID / AIR
INSTALLATION LOCATION: HVAC-PROCESS / HEAT DISTRIBUTION / COOLING / AIR VENTILATION
MOUNTING: PIPE / DUCT
ATTACHABLE PRODUCTS: MF-06-K / MF-15-K / TH08-MS 400MM / TH08-VA 400MM
| Brand: S+S REGELTECHNIK |
| Device type: TRANSMITTER |
| Primary measurement: TEMPERATURE |
| Measurable quantities: TE |
| Measuring range: –50...+150 °C |
| Factory settings: +0…+50°C |
| Installation location: HVAC-PROCESS, HEAT DISTRIBUTION, COOLING, AIR VENTILATION |
| Measurement type: PROBE |
| Probe length: 400MM |
| Wired connectivity: 4...20mA |
| Probe thickness: 6MM |
| Wireless connectivity: NO WIRELESS CONNECTIVITY |
| Application: LIQUID, AIR |
| Mounting: PIPE, DUCT |
| Power supply: 24Vdc |
| Protection type: IP67 |
| Housing features: PLASTIC HOUSING, WHITE, WITH QUICK-LOCKING SCREWS |
| Display: WITH DISPLAY |
Tuotenimi / Viivakoodi: :
TM65-I 400mm LCD / 1101-7122-2089-90030700.pdf
Download
