KFTM-CO2-W

https://www.auteknik.com/web/image/product.template/15696/image_1920?unique=2e6c7ce

BRAND: S+S REGELTECHNIK
DEVICE TYPE: TRANSMITTER
MEASUREMENTS: TEMPERATURE / HUMIDITY / CARBON DIOXIDE
COMPATIBILITY: VOLTAGE SIGNAL(0…10v) / CURRENT SIGNAL(4…20mA) / RELAY
POWER SUPPLY: 24VAC/DC
HOUSING FEATURES: PLASTIC HOUSING
MEASURING RANGE: –35...+80 °C / 0...100 % RH / 0...5000 ppm CO2
FACTORY SETTINGS: 0…2000 ppm CO2
PROBE LENGTH: 200MM
PROBE THICKNESS: 20MM
MEASUREMENT TYPE: PROBE MEASUREMENT
APPLICATION: AIR
INSTALLATION LOCATION: HVAC-PROCESS / AIR VENTILATION
MOUNTING: DUCT

Login to see price

Not Available For Sale

  • Brand
  • Device type
  • Primary measurement
  • Measurable quantities
  • Measuring range
  • Measuring range
  • Measuring range
  • Factory settings
  • Installation location
  • Installation location
  • Measurement type
  • Probe length
  • Wired connectivity
  • Wired connectivity
  • Wired connectivity
  • Probe thickness
  • Wireless connectivity
  • Application
  • Mounting
  • Power supply
  • Power supply
  • Protection type
  • Housing features
  • Display

This combination does not exist.

Contact Us
Brand: S+S REGELTECHNIK
Device type: TRANSMITTER
Primary measurement: CARBON DIOXIDE
Measurable quantities: TE / RH / CO2
Measuring range: –35...+80 °C, 0...100 % RH, 0...5000 ppm CO2
Factory settings: 0…2000 ppm CO2
Installation location: HVAC-PROCESS, AIR VENTILATION
Measurement type: PROBE
Probe length: 200MM
Wired connectivity: 0...10V, 4...20mA, RELAY
Probe thickness: 20MM
Wireless connectivity: NO WIRELESS CONNECTIVITY
Application: AIR
Mounting: DUCT
Power supply: 24Vac, 24Vdc
Protection type: IP65
Housing features: PLASTIC HOUSING
Display: WITHOUT DISPLAY
Tuotenimi / Viivakoodi: :
KFTM-CO2-W / 1501-8116-7301-200
